TECHNICAL SPECIFICATIONS



Main Technical Parameters

16D/E/F

 25D/E/F

Grinding head

2 spindles

  2 spindles

Thickness of processing glass

4-12mm

  4-12mm

Minimum processing glass size

300x700/300x800/350x650mm

  300x700/300x800/350x650mm

Maximum processing glass size

1600x3000mm

  2500x3600mm

Transmission speed

12-30m/min

 12-30m/min
Chamfer width 0.8-2mm 0.8-2mm
Grinding quantity of bottom 0.2-0.5mm/0.1-0.3mm  0.2-0.5mm/0.1-0.3mm

Dimension(L*W*H)

6200x4250mm

  7200x5050mm

Total power

≈15/16KW

  ≈15/16kW

Voltage

380V/50Hz

  380V/50Hz
Machine weight 5000KG 6500KG
Machine Effciency  4pcs/min(1000x800mm)  4pcs/min(1000x800mm)
